Introduction

This page presents a glossary of key terms related to the study of past environmental conditions and is aimed at researchers and those interested in related disciplines who benefit from some understanding of palaeoenvironmental sciences to advance multi-disciplinary projects.

Authors:
Colin J Courtney Mustaphi, Esther Githumbi
February 2015

Keywords:
palaeo-sciences; palaeoenvironments; research methods; methodology; scientific approaches

Palaeo-

Palaeoenvironmental sciences apply the scientific method toward observing, describing, and understanding earth system process that have operated in the the past and have led to the abiotic and biotic interactions that operate on Earth today. With such information it can be possible to understand how the future of the Earth may evolve and the ecosystem responses to the many changes occurring to Earth’s environments. The suffix, Palaeo-, comes from Greek παλαιός meaning “old, ancient” and is used for many of the disciplines in palaeoenvironmental sciences, such as paleontology, palaeogeography, palaeobotany, and palaeoclimatology.

Sources of palaeoenvironmental information:

Archive
Palaeoenvironmental archives (sometimes called geoarchives) are naturally occurring sources of accumulating or growing material that locks in and preserves information about the surrounding environment. For example, the sediments depositing in a lake accumulate and preserve a record of the conditions surrounding a lake. As the sediments pile up they can maintain this record over hundreds, thousands or more years, and can be studied using palaeoenvironmental techniques. Other palaeoenvironmental archives include other sediments from terrestrial and marine sources, cave deposits, volcanic deposits and glacial ice. Biogenic sources can include growth rings in shells and bones, and tree rings. Other sources of past environmental conditions include historical accounts, archaeological information, weather station data, and historical photographs and maps.

Key Terms

Proxy data
An indirect measure of a variable that cannot be directly measured. For example, we cannot directly measure past drought conditions using sediments, but we can quantify the abundance of desert plants based on the pollen they produced and was subsequently deposited, and this gives us details about changes to the vegetation and acts as one proxy for understanding droughts.

Multi-proxy approach
A much more robust understanding of past environmental conditions can be established by examining multiple lines of evidence through the analysis of a number of proxies.

Palaeoecology
The study of ecological relationships throughout the past (Brewer et al., 2012). This type of research helps us understand how the current landscapes evolved into what we see today and can be used to inform land management decisions for the future.

Palaeoenvironmental archive
In certain environments, materials accumulate or grow and contain a signal of the surrounding environmental conditions at the time of deposition (Brewer et al., 2012).

Palynology
The study of contemporary and fossil microscopic organic remains (“palynomorphs“), including pollen and spores. Siliceous and calcareous remains of organisms, such as the exoskeletons of diatoms and foraminifera are not included in this field. An integral part of palaeoecological research, palynology can yield important data on species composition and change therein over time, and acts as a proxy for different environmental factors.

Palynomorphs
Microscopic organic plant and animal remains found in sedimentary rock and sediment cores. These include pollen, vascular plant spores, fungal spores, algal spores, dinoflagellate cysts, and arthropod remains. Palynomorphs typically range in size from about 5 μm to 500 μm, they require specific conditions to survive making them useful indicators of climate and environment change.

Stratigraphy
A view of the layers of sedimentary deposits. Sedimentary layers from a variety of depositional environments archive a wealth of proxy information about past environmental and climate history of an area.

Palaeoenvironmental Proxies

Charcoal
Charcoal and ash result from the incomplete burning of biomass from natural and anthropogenic fires. Charcoal accumulates in depositional environments, such as soils, swamps, lakes, oceans and ice, and can be classified by size fractions that largely relate to the distance it is transported from the source fire. Microscopic charcoal, often macroscopic charcoal, >100 μm, may only be transported from within the watershed or tens of kilometers during high-convection fires (Pisaric, 2002; Tinner et al., 2006). Larger, megascopic charcoal may be deposited where it is produced and be found in soils, sedimentary rock, and extrusive volcanic rocks.

Diatoms

Diatoms are photosynthesizing alage, and among the most common types of phytoplanktom. Most diatoms are unicellular, although they can exist as colonies in the shape of filaments or ribbons (e.g. Fragilaria), fans (e.g. Meridion), zigzags (e.g. Tabellaria), or stars (e.g. Asterionella).  They  are enclosed within a cell wall made of silica (hydrated silicon dioxide) called a frustule. These frustules show a wide diversity in form, but are usually almost bilaterally symmetrical, hence the group name. Fossil  evidence suggests that they originated during, or before, the early Jurassic Period. Only male gametes of centric diatoms are capable of movement by means of flagella.

Diatom communities are a popular tool for monitoring conditions of the past and present (because the silica cell walls do not decompose, diatoms in marine and lake sediments can be used to interpret conditions in the past). Palaeoecology is a field that utilizes both living and sub-fossil diatom valves that are preserved in marine and freshwater sediments, and are commonly used in studies of water quality(as they have specific salinity, temperature and other environmental tolerances).

Diatom images from http://www.ucl.ac.uk/GeolSci/micropal/diatom.html





Macroremains and macrofossils

Non-pollen palynomorphs
All palynomorphs found in a sample that are not pollen, typically referring to fungal and algal spores.

Oribatid mites

Phytoliths

Pollen

Pollen is a fine to coarse powder containing the microgametophytes of seed plants, which produce the male gametes (sperm cells). Pollen grains have a hard coat made of sporopollenin that protects the gametophytes during the process of their movement from the stamens to the pistil of flowering plants or from the male cone to the female cone of coniferous plants. If pollen lands on a compatible pistil or female cone, it germinates, producing a pollen tube that transfers the sperm to the ovule containing the female gametophyte. Individual pollen grains are small enough to require magnification to see detail. The study of pollen is called palynology and is highly useful in paleoecology, paleontology, archeology, and forensics.
Pollen in plants is used for transferring haploid male genetic material from the anther of a single flower to the stigma of another in cross-pollination. In a case of self-pollination, this process takes place from the anther of a flower to the stigma of the same flower. The earliest reported observations of pollen under a microscope are likely to have been in the 1640s by the English botanist Nehemiah Grew who described pollen, the stamen, and correctly predicted that pollen is required for sexual reproduction in flowering plants.

Stomata

Sedimentology

Magnetic Susceptibility
Magnetic Susceptibility is basically how ‘magnetisable’ a material, it is a measure of the strength of the reaction to a magnetic field. The reaction whether extremely weak or strong tells us what elements are found in the sediment.  For example soil containing iron oxide will have a high magnetic susceptibility as it is highly magnetic while others containing quartz will not show a visible reaction to the magnet. It is important as it acts as an indicator of soil properties such as waterlogging and processes such as burning.

Particle Size Distribution Analysis
Sediments and sedimentary rock are composed of various clastic, biogenic and chemical deposits that accumulate in a basin. By investigating the size distributions of these sediments informs us about the energy regime that transported and led to the deposition of this material. How the energy regime changed through time can also give us palaeoenvironmental information that can help us interpret other important changes in fossil material, giving a more holistic interpretation of past environmental conditions. The various techniques of particle size distribution analysis are succinctly presented by Syvitski (2007).

Loss-on-ignition analysis
Sediment organic and carbonate content can be calculated from the weight loss from burning the sediments in an oven at different temperatures (Heiri et al., 2001; Wang et al., 2012).

References:

Brewer S., Jackson S.T., Williams J.W. 2012. Paleoecoinformatics: applying geohistorical data to ecological questions. Trends in Ecology and Evolution, 27 (2): 104-112.

Heiri O, Lotter AF, Lemcke G (2001) Loss on ignition as a method for estimating organic and carbonate content in sediments: reproducibility and comparability of results. Journal of Paleolimnology 25: 101–110. doi: 10.1023/a:1008119611481

Pisaric, M. F. (2002). Long-distance transport of terrestrial plant material by convection resulting from forest fires. Journal of Paleolimnology, 28(3), 349-354.

Rucina SM, Muiruri VM, Kinyanjui RN, McGuiness K, Marchant R. 2009. Late Quaternary vegetation and fire dynamics on Mount Kenya. Palaeogeography, Palaeoclimatology, Palaeoecology 283: 1-14.

Syvitski, JP (Ed.). (2007). Principles, methods and application of particle size analysis. Cambridge University Press.

Tinner, W., Hofstetter, S., Zeugin, F., Conedera, M., Wohlgemuth, T., Zimmermann, L., & Zweifel, R. (2006). Long-distance transport of macroscopic charcoal by an intensive crown fire in the Swiss Alps-implications for fire history reconstruction. The Holocene, 16(2), 287-292.

Wang, X., Wang, J., & Zhang, J. (2012). Comparisons of three methods for organic and inorganic carbon in calcareous soils of northwestern China. PlOS one, 7(8), e44334.

http://www.ucl.ac.uk/GeolSci/micropal/diatom.html
